Pizza Topping

Also known as: Stacking Elements, Layering Elements

Intent

Stack an element on top of another element.

Problem

The normal flow of the document is from top to bottom. In some cases, we want to stack an element on top of another element. When we do this, it must not create extra gaps or margins (more details below).

Example in ZenUML

The diagram is rendered in three layers. From bottom to top, they are the Background, the Lifeline Layer and the Message Layer.

Solution

<div class="sequence-diagram relative">
  <div class="lifeline-layer absolute h-full w-full"></div>
  <div class="message-layer"></div>
</div>

Let me explain the tailwind CSS classes one by one:

1. relative: To give lifeline-layer height (see below).
2. absolute: To remove the Lifeline Layer from the normal flow of the document.
3. h-full: To make the Lifeline Layer as high as the sequence diagram. Both relative and absolute are required to make this work<sup>1</sub>.
4. w-full: To make the Lifeline Layer as wide as the sequence diagram. Due to absolute, the Lifeline layer will not have width by default².

The message layer is in the normal flow and it gets the height from the content.

1. Without absolute, h-full (or any percentage) has no effect, because its height will have impact one the flow. With absolute, the Lifeline layer will be get the height from the nearest positioned ancestor. relative is used to position its parent.
2. You may notice that ZenUML/core does not use w-full. It is because the Lifelines are also absolutely positioned. So the width of the Lifeline Layer is not important.

Discussion

A special requirement for this pattern is that the Lifeline Layer must dynamically adjust its height with the Message Layer.

Transform can also be used to shift the element. However, it is not recommended because it will create extra gaps or margins.

Grid can also be used to stack elements. The support is pretty good (95+%). It has extra benefits such as you get height and width for free. It is a recommended solution if your audience are using modern browsers.
